Our Price $20 off >

US$990.00

Regular Price >

US$1,190.00

Item#

ENC-500

Description

300ft Long Range 5~50mm Telephoto Varifocal Night Vision Camera

Camera Housing

IP-66 Weatherproof Metal Housing w/ Rain & Sunshield

Image Sensor

Sony 1/3" Super HAD Color CCD

Lens

Auto Iris 5~50mm Vari-Focal Manual Zoom Lens (FOV: 65º ~ 7º Diagonally)

Viewing Angles

Refer the above pic of the viewing angle comparison to know how large area the applicable lens can see and click the following link to review the FOV comparison of all applicable lenses.
http://www.ezspycam.com/R-img-FOV-variation.htm

LED

228 Invisible 950NM IR LEDs (Life span - Appx. 20,000hrs)

CdS Sensor

Makes LEDs turn on-off at about 10 LUX automatically

Night Visibility

300ft in the total darkness when LEDs are turned on.

Click the left image to play the video clip sample.

Also click the following link or paste it to your web browser to re view all available night vision image samples.
http://www.ezspycam.com/R-img-daynightvision.htm

Day Visibility

3 inches from the camera to infinity.

Click the left image to play the video clip sample.

Also click the following link or paste it to your web browser to re view all available night vision image samples.
http://www.ezspycam.com/R-img-daynightvision.htm

Video Resolution

480 TVL (410K pixel)

Video Out

1Vp-p Composite Video 75 ohms

Video Connector

RCA Jack

Minimum Illumination

0.01 LUX in Color (Daytime) / 0.000 LUX in B&W (Night)

Signal System

NTSC for USA, Canada, Asian countries etc...
(*Optional: PAL for Eastern Europe & France, etc...)

Electronic Shutter

NTSC=1/60~1/100,000/Sec (28 Steps) ; PAL=1/50~1/100,000/Sec (28 Steps)

Luminance S/N Ratio

Over 48dB

Special Feature

Auto Gain Control (AGC) / Auto Backlight Compensation / Auto Backlight Compensation

Weight / Dimension

8.38LBS (3.8kg)  / Ø150xL224mm (Ø5.9”xL8.81”)

Overheat Protection

Built-in Cooling Fan & 70°C Thermal Protection Sensor

Operating
Temperature

32ºF ~ 131ºF ; Humidity - 10%RH ~ 80%RH

Warranty

One Year Full Warranty including Parts & Labor

Camera
Set Includes

Metal Mounting Bracket Set; Removable Sunshield; Installation Guide; Spec Sheet

Power Supply of AC Free Volts w/ SMPS (AC 90V ~ 240V)
*Optional - DC 13.2V-2.7AMP w/DC-DC Converter (DC 9V ~ 18V)

Special Instruction

*This camera never should be submerged and exposed under heavy storm or harsh raining environment for long period.

*Click the following link or paste it to you web browser to review a proper way to purchase suitable cameras or accessories for your need.
http://www.ezspycam.com/PG-NightVsionCam.htm

*Click the following link or paste to your web browser to make sure to review Installation Guide.
http://www.ezspycam.com/IG-NV-VarifocalCam.htm

1-Year warranty will not cover if the camera or cable malfunctions that caused by improper installation.
