Turn
your camera into Nightvision camera & view Impossible-to-see total-dark areas
Indoor
& Outdoor Use
Home
security, Business surveillance, Home alone Pet watch, School Security,
Child Monitoring, Police Raid
Cash counter surveillance, Baby Watch, Office Surveillance, Infants
safety, Property security, Animal Watch
Ground Troop Raid, Wild Animal video, Zoo keeping, Bird net watch, Garden watch, Natural
Life observation
Backyard Watch, Outdoor security, Hidden surveillance, Spy video, Live
video, Video surveillance, Nanny Cam
|
| Item# |
ENC-907A |
ENC-907B |
| Description |
Heavy
Duty Total Invisible IR Illuminator |
Heavy
Duty Long Range IR Illuminator |
| IR
LED Q'ty |
140pcs |
140pcs |
| IR-LED Angle |
70º |
70º |
| Wave
Length |
950NM(Invisible) |
850NM(Visible) |
Visibility
in using
1/3" Sony CCD |
up
to 90ft |
up
to 160ft |
| Power
Input & Consumption |
Dual
DC12V & AC24V / 400mA |
Dual
DC12V & AC24V / 450mA |
| Weight |
765gr(27oz) |
765gr(27oz) |
| Dimension |
L6.75"
x H5" x D4.25" |
L6.75"
x H5" x D4.25" |
| Housing |
IP65
All Weather Metal Housing |
IP65
All Weather Metal Housing |
| Red
Glow on LED |
No
& Totally Invisible |
Yes,
but still IR light is invisible |
| Night
Visibility
|
 |
Click the above images to play the video clip sample.
Above video clip was shot w/ #EBC-100 Camera (4.3mm Board Lens) |
| Built-in |
DC
+12V Regulator Circuits & Cooling Fan
|
|
CdS Sensor to Turn On-Off IR LEDs at about 10.0 LUX
|
| Special
Functions |
Built-in
+12V regulator circuits for over 2-year life span of LEDs
|
|
Required
Camera Specification
|
Your
camera must feature or capable to turn it on manually if available any
one of the required specification among Daynight
function, AGC (Auto Gain Control), ALG (Auto Level Control), Auto
Change of Color Video to B&W at Night, or IR-cut Filtered
in order to view the IR light. Additionally it is strongly recommended
the LUX level of your camera offers at least
0.01 LUX or lower
in order to view the IR light up to the maximum distance as it
offered; otherwise the IR light won’t be viewed correctly.
|
|
Auto
Iris Lens
|
Should
be set to ALC (Auto Level Control) for the correct IR vision
|
|
Operating
Temperature
|
-20ºC
~ 50ºC (-4ºF ~ 122ºF) ; Humidity - 10%RH ~ 80%RH
|
| Illuminator
Set Includes |
Built-in
Mounting Bracket
Set, 12V AC/DC Power Supply, & Quick Starter Guide
|
|
