| Item# |
EPD-0860
|
| CPU |
Intel Celeron 2.0GHz or higher
|
| Main Board |
Intel 845 chipset or higher
|
| Memory |
256MB DDR
|
| HDD |
250GB 7200RPM
|
| VGA Card |
On Board
|
| OS |
Windows XP Home Edition
|
| Mouse, Keyboard |
PS/2 Compatible
|
| Camera Input |
8 Ports
|
| Sensor Input |
4 Ports
|
| Audio Input |
2 Port
|
| Control Output |
2 Ports
|
| Display Speed |
60fps (NTSC), 60fps (PAL)
|
| Recording Speed |
60fps (NTSC), 60fps (PAL)
|
| Compression |
MPEG-4
|
| Image Resolution |
640x480, 640x240, 320x240
|
| Image Size |
2~4KB
|
| Motion Detection |
Regions per channel / Adjustable sensitivity
|
| Recording Mode |
Continuous, Motion, Sensor, Pre-Alarm, Scheduled
|
| Remote Control |
PSTN, ISDN, DSL, LAN and TCP/IP
|
| Backup |
CD-RW, USB, DVD
|
| PTZ |
RS-232/422/485 Interface (Option)
|
| Case Type |
Mini Desktop Case
|
| Includes |
Remote
Client Software CD-ROM,
User’s Manual, Power Cable, PDA
Viewer, Mouse, Keyboard |
| Download |
DVR
Software Instruction
- Click the following link or paste
it to your web browser. http://www.ezspycam.com/download/MN-DVR.pdf |
| Networking
Software Instruction - Click the following link or paste
it to your web browser. http://www.ezspycam.com/download/MN-iCENS120.pdf |
| Multi-DVR
Management Software Instruction - Click the following link or paste
it to your web browser. http://www.ezspycam.com/download/MN-DVR-manageman.pdf |
| PDA
Viewer Software Instruction - Click the following link or paste
it to your web browser. http://www.ezspycam.com/download/MN-PDA110.pdf |
| POS
Installation Guide
- Click the following link or paste
it to your web browser. http://www.ezspycam.com/download/MN-POSman.pdf |
