Sale Price $30 off >

US$199.00

Regular Price >

US$229.00

Item#

EBC-100

Image Sensor

Sony 1/3" Super HAD Color CCD

Signal System

NTSC for USA, Canada, Asian countries etc...
(*Optional: PAL for Eastern Europe & France, etc...)

Lens

Fixed 4.3mm Board Lens

Viewing Angles

Refer the above pic of the viewing angle comparison to know how large area the applicable lens can see and click the following link to review the FOV comparison of all applicable lenses.
http://www.ezspycam.com/R-img-FOV-variation.htm

Day Visibility

3 inches from the camera to infinity.

Click the left image to play the video clip sample.

Also click the following link or paste it to your web browser to re view all available night vision image samples.
http://www.ezspycam.com/R-img-daynightvision.htm

Night Vision in
Light supporting
of IR Illuminator

Click the left image to play the video clip sample.

Also click the following link or paste it to your web browser to re view all available night vision image samples.
http://www.ezspycam.com/R-img-daynightvision.htm

Video Resolution

480 TVL (410K pixel)

Video Connector

RCA Jack

Power Consumption

DC 12V±1V / 150mA±10%

Minimum Illumination

0.01 LUX (Sees in virtual darkness)

Weight / Dimension

2.82oz (80g) - Camera only / Φ30mm x L77mm (Φ1.18”xL3.03”)

Operating Temp

-5ºC ~ 40ºC (23ºF ~ 104ºF) / RH95% Max

Electronic Shutter

1/60~1/100,000/Sec

Special Feature

Auto White Balance (AWB) / Auto Gain Control (AGC) / IR Filter

Warranty

One Year Full Warranty including Parts & Labor

Camera
Set Includes

AC/DC 12V–300mA Power Supply; Installation Guide; Spec Sheet
