Item#
|
EPC-100
|
|
Description
|
4"
Miniature PTZ Color Camera w/ 3x Digital Zoom
|
|
Item#
|
EPC-101
|
|
Description
|
4"
Miniature PTZ Color Camera in Wall-mountable Steel Housing w/ 3x Digital Zoom
|
|
Item#
|
EPC-102
|
|
Description
|
Economic
4"
Miniature PTZ Color Camera (No Digital Zoom)
|
|
Item#
|
EPC-103
|
|
Description
|
Economic
4"
Miniature PTZ Color Camera in Wall-mountable Steel Housing (No
Digital Zoom)
|
|
Item#
|
EPC-104
|
|
Description
|
4"
Mini Pan Tilt Zoom Color Camera
w/ Auto Iris Manual adjustable 4~9mm Varifocal Lens
|
|
Item#
|
EPC-105
|
|
Description
|
4"
Mini Pan Tilt Zoom Color Cam in
Wall-mountable Housing w/
Auto Iris Manual adjustable 4~9mm Varifocal Lens
|
|
Sensor
|
Sony
1/3" Super HAD Color
CCD
|
|
Lens
|
3.8mm
Fixed Board Lens
|
|
Communication
|
RS-485
(Pelco-D Protocol)
|
|
Baud
Rate
|
2400
BPS
|
|
Day
Visibility
&
Viewing
Angles
Video Sample
|
 3
inches from the camera to infinity.
Click the left image to play the video clip sample.
Also click the following link or paste it to your web
browser to re view all available night vision image samples.
http://www.ezspycam.com/R-img-daynightvision.htm
|
|
Video
Resolution
|
480
TVL (410K
pixel)
|
|
Video
Out
|
1Vp-p
Composite Video
75 ohms
|
|
Cable
Connector
|
DC-12V Power-in Plug (Red)
Video-out BNC Jack (Yellow)
Bare Wires (Black to - & White to + on IR
Converter or other RS-485
Communication
Interface device)
|
|
Minimum
Illumination
|
0.01
LUX
|
|
Pan
Range & Speed
|
320º
& 35º/ Sec (16-step Pan Angel Preset by Rotary Switch (One Step
by 20º)
|
|
Tilt
Range & Speed
|
90º
& 40º/ Sec
|
|
Electronic
Shutter
|
1/60~1/100,000
per sec
|
|
Luminance
S/N
Ratio
|
Over
48dB
|
|
Special
Feature
|
Up
to 39 Cameras can be controlled with the included IR Remote
Control Unit or other RS-485 Communication
Interface
device
|
|
Weight
/ Dimension
|
Camera
only - 1.0LBS
(454g)
/ Ø107
x H105mm (4.21" x 4.13")
|
|
Camera
w/ Outdoor Metal Housing - 2.25LBS
(1020g) / L254
x H254 x Ø114mm (10" x 10" x 4.5")
|
|
Operating
Temperature
|
32ºF ~
131ºF ; Humidity - 10%RH ~ 80%RH
|
|
Warranty
|
One Year
Full Warranty including Parts & Labor
|
|
Camera
Set Includes
|
Wireless
Remote Control Set;
Mounting Bracket Set; AC/DC 12V–1.5A Power
Supply; Installation Guide; Spec Sheet
|
|
*Click
the following link or paste to your web browser to
make sure to review Installation Guide.
http://www.ezspycam.com/IG-EPC-100.htm
1-Year warranty will not cover
if the
camera or cable malfunctions that
caused by improper
installation.
|
|
*Click
the following link or paste to your web browser to
download User's Guide.
http://www.ezspycam.com/UG-EPC-100.pdf
*Click
the following link or paste to your web browser to
download Typical PTZ connection diagram.
http://www.ezspycam.com/Download/IG-PTZcam-connection.pdf
|
